PUDDLE FLANGES
Description
The Puddle Flange is used where the down conductor must pass through a roof or waterproof membrane. The flats of the flange are made waterproof by fixing with glue, concrete or specialist materials.
For use with Copper Conductor
| L (mm) | W (mm) | Unit Weight (Kg) | Code |
|---|---|---|---|
| 600 | 150 x 150 | 1.68 | CPF |
Material : Copper
For use with Aluminium Conductor
| L (mm) | W (mm) | Unit Weight (Kg) | Code |
|---|---|---|---|
| 600 | 150 x 150 | 0.54 | APF |
