TINNED HARD DRAWN COPPER BARS
Description
This bar has a high conductivity making it ideal for use in high voltage distribution and control applications.
| Size W x H (mm) | C.S.A. (mm)2 | Weight Per Metre (Kg) | Standard Length (m) | Code |
|---|---|---|---|---|
| 10 x 5 | 50 | 0.45 | 4 | HDT1005 |
| 15 x 5 | 75 | 0.67 | 4 | HDT1505 |
| 16 x 6 | 96 | 0.86 | 4 | HDT1606 |
| 20 x 3 | 60 | 0.54 | 4 | HDT2003 |
| 20 x 4 | 80 | 0.71 | 4 | HDT2004 |
| 20 x 5 | 100 | 0.89 | 4 | HDT2005 |
| 20 x 10 | 200 | 1.78 | 4 | HDT2010 |
| 25 x 3 | 75 | 0.67 | 4 | HDT2503 |
| 25 x 4 | 100 | 0.89 | 4 | HDT2504 |
| 25 x 5 | 125 | 1.11 | 4 | HDT2505 |
| 25 x 6 | 150 | 1.34 | 4 | HDT2506 |
| 30 x 5 | 150 | 1.33 | 4 | HDT3005 |
| 30 x 6 | 180 | 1.61 | 4 | HDT3006 |
| 30 x 10 | 300 | 2.67 | 4 | HDT3010 |
| 32 x 6 | 192 | 1.61 | 4 | HDT3206 |
| 38 x 6 | 228 | 2.03 | 4 | HDT3806 |
| 40 x 3 | 120 | 1.07 | 4 | HDT4003 |
| 40 x 5 | 200 | 1.78 | 4 | HDT4005 |
| 40 x 6 | 240 | 2.16 | 4 | HDT4006 |
| 40 x 10 | 400 | 3.56 | 4 | HDT4010 |
| 50 x 4 | 200 | 1.78 | 4 | HDT5004 |
| 50 x 5 | 250 | 2.24 | 4 | HDT5005 |
| 50 x 6 | 300 | 2.68 | 4 | HDT5006 |
| 50 x 8 | 400 | 3.57 | 4 | HDT5008 |
| 50 x 10 | 500 | 4.48 | 4 | HDT5010 |
| 60 x 5 | 300 | 2.67 | 4 | HDT6005 |
| 60 x 10 | 600 | 5.36 | 4 | HDT6010 |
| 75 x 5 | 375 | 3.35 | 4 | HDT7505 |
| 75 x 6 | 450 | 4.01 | 4 | HDT7506 |
| 80 x 6 | 480 | 4.29 | 4 | HDT8006 |
| 80 x 8 | 640 | 5.71 | 4 | HDT8008 |
| 80 x 10 | 800 | 7.12 | 4 | HDT8010 |
| 100 x 4 | 400 | 3.57 | 4 | HDT10004 |
| 100 x 5 | 500 | 4.46 | 4 | HDT10005 |
| 100 x 6 | 600 | 5.35 | 4 | HDT10006 |
| 100 x 10 | 1000 | 8.94 | 4 | HDT10010 |
| 100 x 12 | 1200 | 10.7 | 4 | HDT10012 |
