TINNED COPPER TAPES
Description
This Tape is used on both lightning protection and earthing applications. It is annealed for ease of use and has radiused edges.
| Size W x H (mm) | C.S.A. (mm)2 | Weight Per Metre (Kg) | Standard Coil Size (m) | Code |
|---|---|---|---|---|
| 20 x 1.5 | 30 | 0.27 | 100 | TCT2015 |
| 20 x 3 | 60 | 0.54 | 100 | TCT2003 |
| 20 x 4 | 80 | 0.71 | 75 | TCT2004 |
| 20 x 5 | 100 | 0.89 | 75 | TCT2005 |
| 25 x 3 | 75 | 0.67 | 50 | TCT2503 |
| 25 x 4 | 100 | 0.89 | 50 | TCT2504 |
| 25 x 5 | 125 | 1.12 | 40 | TCT2505 |
| 25 x 6 | 150 | 1.34 | 25 | TCT2506 |
| 30 X 3 | 90 | 0.80 | 50 | TCT3003 |
| 30 X 4 | 120 | 1.07 | 40 | TCT3004 |
| 30 X 5 | 150 | 1.34 | 40 | TCT3005 |
| 31 X 3 | 93 | 0.83 | 50 | TCT3103 |
| 31 X 6 | 186 | 1.66 | 30 | TCT3106 |
| 38 X 3 | 114 | 1.02 | 50 | TCT3803 |
| 38 X 5 | 190 | 1.69 | 30 | TCT3805 |
| 38 X 6 | 228 | 2.03 | 25 | TCT3806 |
| 40 X 3 | 120 | 1.07 | 40 | TCT4003 |
| 40 x 4 | 160 | 1.43 | 30 | TCT4004 |
| 40 x 5 | 200 | 1.78 | 25 | TCT4005 |
| 40 x 6 | 240 | 2.14 | 25 | TCT4006 |
| 40 x 8 | 320 | 2.85 | 20 | TCT4008 |
| 50 x 3 | 150 | 1.34 | 40 | TCT5003 |
| 50 x 4 | 200 | 1.78 | 30 | TCT5004 |
| 50 x 5 | 250 | 2.23 | 20 | TCT5005 |
| 50 x 6 | 300 | 2.68 | 20 | TCT5006 |
| 50 x 8 | 400 | 3.57 | 20 | TCT5008 |
| 60 X 5 | 300 | 2.68 | 20 | TCT6005 |
| 60 X 6 | 360 | 3.21 | 15 | TCT6006 |
| 60 x 8 | 480 | 4.28 | 12 | TCT6008 |
| 70 x 6 | 420 | 3.75 | 15 | TCT7006 |
| 75 X 6 | 450 | 4.01 | 7 | TCT7506 |
| 80 x 6 | 480 | 4.28 | 12 | TCT8006 |
