BARE ALUMINIUM TAPES
Description
These tapes are used on lightning protection system application. It is annealed for ease of use and has radiused edges.
| Size W x H (mm) | C.S.A. (mm)2 | Weight Per Metre (Kg) | Standard Coil Size (m) | Code |
|---|---|---|---|---|
| 12.5 x 1.5 | 18.75 | 0.05 | 50 | BAT1215 |
| 19 x 2 | 38 | 0.10 | 50 | BAT1902 |
| 20 x 1 | 20 | 0.05 | 50 | BAT2001 |
| 20 x 3 | 60 | 0.17 | 50 | BAT2003 |
| 25 x 3 | 75 | 0.21 | 50 | BAT2503 |
| 25 x 4 | 100 | 0.28 | 50 | BAT2504 |
| 25 x 6 | 150 | 0.42 | 50 | BAT2506 |
| 30 x 3 | 90 | 0.25 | 50 | BAT3003 |
| 40 x 3 | 120 | 0.34 | 50 | BAT4003 |
| 40 x 6 | 240 | 0.68 | 50 | BAT4006 |
| 50 x 3 | 150 | 0.42 | 50 | BAT5003 |
| 50 x 4 | 200 | 0.56 | 50 | BAT5004 |
| 50 x 6 | 300 | 0.85 | 50 | BAT5006 |
| 50 x 8 | 400 | 1.13 | 50 | BAT5008 |
| 60 x 3 | 180 | 0.51 | 50 | BAT6003 |
| 60 x 4 | 240 | 0.68 | 50 | BAT60004 |
| 60 x 6 | 360 | 1.02 | 50 | BAT6006 |
